MikroTik Cloud Core Router, CCR2216-1G-12XS-2XQ
Your price excl. VAT
2 083.60 EUR
| Recycling fee | 0.07 EUR |
|---|---|
| Your price with RF | 2 083.67 EUR |
| Your price incl. VAT (21%) | 2 521.24 EUR |
| blank |
Availability
at our branches
at our branches
| Manufacturer |
MikroTik |
|
|---|---|---|
| Code | 10300694 | |
| Part No. | CCR2216-1G-12XS-2XQ | |
| Warranty | 24 months | |
12POW150
74.80 EUR excl. VAT
90.60 EUR incl. VAT
In Stock
PW48V-12V150W
74.80 EUR excl. VAT
90.60 EUR incl. VAT
In Stock
MT-HotSwapFan
28.86 EUR excl. VAT
34.97 EUR incl. VAT
In Stock
XQ+DA0001
28.86 EUR excl. VAT
35.01 EUR incl. VAT
In Stock
XQ+DA0003
42.75 EUR excl. VAT
51.81 EUR incl. VAT
In Stock
XQ+31LC02D
170.94 EUR excl. VAT
206.92 EUR incl. VAT
In Stock
CRS504-4XQ-IN
597.13 EUR excl. VAT
722.61 EUR incl. VAT
In Stock
XQ+31LC10D
260.71 EUR excl. VAT
315.54 EUR incl. VAT
In Stock
PCU5E-1YW-MS
0.57 EUR excl. VAT
0.69 EUR incl. VAT
In Stock
PCU5E-5-MSC
3.46 EUR excl. VAT
4.19 EUR incl. VAT
Expected 12.2.2025
Parameters
Download
Video
GPSR
Technical parameters
Connectors and Interfaces
M.2 slots:
2
Multiple WAN:
Yes
LAN speed:
(1) 10/100/1000Mbps
Gigabit LAN:
Yes
Optical interfaces:
(12) 1G/10G/25Gbps + (2) 100Gbps
Serial port:
RJ45
Power
Power type:
Mains power (230V)
Redundant power supply:
Yes
Max. power consumption [W]:
121
Power via connector/terminal:
230V AC
Physical characteristics
Design:
Rackmount
"U" positions:
1
Fans:
Yes
Chassis design:
Metal
Operating temperature [°C]:
-20 up to 60
Width [mm]:
443
Height [mm]:
44
Depth [mm]:
367
Hardware
CPU:
AL73400
CPU frequency [MHz]:
2000
CPU cores:
16
Internal storage [MB]:
128
RAM [MB]:
16384
Software
Operating system:
RouterOS - L6
IPv6 support:
Yes
Default IP address:
192.168.88.1
Default login and password:
admin / -
Video
Product description
The new flagship Cloud Core Router 2216 with a very strong configuration designed for the most exposed places of your network and in compared to CCR1072 it is up to 4x more powerful!. There is 12x SFP28 at 1/10/25 Gbps, 2x QSFP28 at speeds of 100 Gbps and 1x 10/100/1000 Mbps ethernet, RJ45 console port, 4 hotswap fans, 2 redundant hotswap sources with input voltage 100 - 240 V and (2) M.2 PCI-e slots for SSD.
RouterOS v7 level 6 is pre-installed, offering 128 MB of internal storage and 16 GB of DDR4 RAM. The maximum power consumption of the device is 121 W with connected peripherals (80 W without peripherals).
Key Features
Package Contents
Articles and reviews
SFP compatibility listDownload
CE Datasheet Firmware (RouterOS / SwOS)GPSR
