MaxLink MAXPI60W2x2 PoE injector - 802.3af/at, 55V, 1.1A, 60W, 1Gbit, 2xLAN, 2XPoE
MaxLink MAXPI60W2x2 PoE injector - 802.3af/at, 55V, 1.1A, 60W, 1Gbit, 2xLAN, 2XPoE
×
0/0
Your price excl. VAT
72.79 EUR
| Recycling fee | 0.07 EUR |
|---|---|
| Your price with RF | 72.86 EUR |
| Your price incl. VAT (21%) | 88.16 EUR |
| blank |
Availability
at our branches
at our branches
| Manufacturer |
MaxLink |
|
|---|---|---|
| Code | 10981225 | |
| Part No. | MAXPI60W2x2 | |
| Warranty | 24 months | |
Parameters
Download
GPSR
Technical parameters
Connectors and Interfaces
Ethernet speed [Mb/s]:
10/100/1000
Gigabit LAN:
Yes
Power
Output Power / 1port [W]:
60
Pin powering:
1,2,7,8 (-), 3,4,5,6 (+)
PoE-Out standards:
802.3af, 802.3at
PoE Out ports:
2
Output Voltage [V]:
55
Physical characteristics
LED indication:
Yes
Operating temperature [°C]:
-30 up to 55
Weight [g]:
460
Width [mm]:
85
Height [mm]:
208
Depth [mm]:
46
Product description
MaxLink PI60 2x2 is a dual-port PoE injector designed for indoor use. It provides 55 VDC power for remote PDs through one PoE port or delivers 30W per port for two remote PDs simultaneously.
It powers terminal devices that support the IEEE802.3af/at standard, such as wireless access points, base stations, high-power cameras, door locks, displays, POS terminals, information kiosks, and other high-power Ethernet terminals.
It supports data transfer speeds of 10/100/1000 Mbps. The effective range is 100 meters over Cat5e/Cat6 cables.
Download
DatasheetGPSR
