Huawei OptiXstar EG8145X6-10 GPON ONT Gateway, WiFi 6

Huawei OptiXstar EG8145X6-10 GPON ONT Gateway, WiFi 6
Huawei OptiXstar EG8145X6-10 GPON ONT Gateway, WiFi 6
×
0/0
Huawei OptiXstar EG8145X6-10 GPON ONT Gateway, WiFi 6
Huawei OptiXstar EG8145X6-10 GPON ONT Gateway, WiFi 6
Huawei OptiXstar EG8145X6-10 GPON ONT Gateway, WiFi 6
Huawei OptiXstar EG8145X6-10 GPON ONT Gateway, WiFi 6
Huawei OptiXstar EG8145X6-10 GPON ONT Gateway, WiFi 6
Huawei OptiXstar EG8145X6-10 GPON ONT Gateway, WiFi 6
Huawei OptiXstar EG8145X6-10 GPON ONT Gateway, WiFi 6
Huawei OptiXstar EG8145X6-10 GPON ONT Gateway, WiFi 6
Huawei OptiXstar EG8145X6-10 GPON ONT Gateway, WiFi 6
Huawei OptiXstar EG8145X6-10 GPON ONT Gateway, WiFi 6
Huawei OptiXstar EG8145X6-10 GPON ONT Gateway, WiFi 6
Huawei OptiXstar EG8145X6-10 GPON ONT Gateway, WiFi 6

Your price excl. VAT
53.50 EUR
Recycling fee 0.06 EUR
Your price with RF 53.56 EUR
Your price incl. VAT (21%) 64.81 EUR
blank
In Stock
PlzeňIn Stock
Externí sklad EATo order within 48h
Externí sklad EUTo order within 48h
Availability
at our branches
Manufacturer

Huawei

Code10907058
Part No.EG8145X6-10
Warranty 24 months
You have a choice of 2 variantscompare all
Huawei OptiXstar EG8145X6-10 GPON ONT Gateway, WiFi 6
gateway, WiFi 6
EG8145X6-10
53.50 EUR
In Stock
Huawei EchoLife EG8145V5 GPON ONT Gateway, WiFi 5
gateway, WiFi 5
EG8145V5
43.08 EUR
In Stock
  • Related products2
Masterlan patch cable UTP, Cat5e, 1m, yellow
PCU5E-1YW-MS

0.57 EUR excl. VAT
0.69 EUR incl. VAT
In Stock
Masterlan comfort patch cable UTP, Cat5e, 5m, gray
PCU5E-5-MSC

3.44 EUR excl. VAT
4.16 EUR incl. VAT
In Stock
Parameters
Download

Product description

The Huawei OptiXstar EG8145X6-10 is an intelligent GPON and Wi-Fi 6 routing-type ONT. It uses the GPON Wi-Fi 6 technology to implement ultra-broadband access, high performance and wide coverage for users. The high forwarding performance ensures the user experience of voice, data and HD video services, and provides customers with an ideal all-optical access solution and future-oriented service support capability.

Device comes from official Czech distribution.

Next Generation Wi-Fi 6 Technology

  • IEEE 802.11a/b/g/n/ac/ax
  • 2x2 MU-MIMO
  • Smart Wi-Fi coverage
  • 574Mbps / 2402Mbps modulation speed
  • 160MHz band width

Smart Service

  • Scheduled Wi-Fi shutdown
  • Smart Wi-Fi sharing: Portal/802.1x authentication
  • SoftGRE-based sharing

Package contents

  • Device
  • DC Power adapter

Download

Datasheet QSG

Bussines information

Dan Pacanda, +420 377 221 177 , dan.pacanda@discomp.cz

Technical parameters

Wireless features

MU-MIMO: Yes
Transmission speed - 5GHz [Mb/s]: 2402
Transmission speed - 2.4GHz [Mb/s]: 574
2.4GHz MIMO: 2 x 2
5GHz MIMO: 2 x 2
Type of antenna: Fixed
Fixed antennas: 2
Antenna gain [dBi]: 7

Optics

Transmission speed: 2.488 / 1.244 Gbps
Wavelength - Tx/Rx [nm]: 1310 / 1490
Transfer type: GPON
Polishing type: APC

Connectors and Interfaces

Ethernet speed [Mb/s]: 10/100/1000
Optical Connectors: (1) SC
LAN speed: (4) 10/100/1000Mbps
Gigabit LAN: Yes

Power

Max. power consumption [W]: 12
Power via connector/terminal: 12V DC

Physical characteristics

Buttons: Reset, WPS, power, WiFi
Operating temperature [°C]: 0 up to 40
Weight [g]: 250
Width [mm]: 155
Height [mm]: 35
Depth [mm]: 105

Software

Default IP address: 192.168.18.1
Default login and password: Epadmin / adminEp
