Ubiquiti UniFi Switch USW-24-POE Gen2
Ubiquiti UniFi Switch USW-24-POE Gen2
×
0/0
Your price excl. VAT
334.16 EUR
| Recycling fee | 0.07 EUR |
|---|---|
| Your price with RF | 334.23 EUR |
| Your price incl. VAT (21%) | 404.42 EUR |
| blank |
Availability
at our branches
at our branches
| Manufacturer |
Ubiquiti |
|
|---|---|---|
| Code | 10901810 | |
| Part No. | USW-24-POE | |
| Warranty | 24 months | |
You have a choice of 3 variantscompare all
UACC-RJ45-Cover
18.58 EUR excl. VAT
22.48 EUR incl. VAT
In Stock
PCU5E-1YW-MS
0.57 EUR excl. VAT
0.69 EUR incl. VAT
In Stock
PCU5E-5-MSC
3.44 EUR excl. VAT
4.16 EUR incl. VAT
In Stock
Parameters
Download
Technical parameters
Connectors and Interfaces
LAN speed:
(24) 10/100/1000Mbps
Optical interfaces:
(2) 1000Mbps
Other features:
Touchscreen
Power
Power type:
Mains power (230V)
PoE type:
PoE-Out (only)
PoE-Out standards:
802.3af, 802.3at
PoE Out ports:
16
PoE budget [W]:
95
Max. power consumption [W]:
25
Power via connector/terminal:
230V AC
Physical characteristics
Design:
Rackmount
Fans:
No
Chassis design:
Metal
Operating temperature [°C]:
-5 up to 40
Width [mm]:
442
Height [mm]:
44
Depth [mm]:
200
General
Switchning capacity [Gbps]:
52
MAC address table:
16000
Jumbo frame [Bytes]:
9000
Packet forwarding rate [Mpps]:
38,69
Software
Management:
UniFi Network
Features:
VLAN, DHCP snooping
Default IP address:
192.168.1.20, Dynamic from DHCP
Default login and password:
ubnt / ubnt
Product description
USW-24-POE is a configurable Gigabit Layer 2 switch with 24 Gigabit Ethernet ports including 16 auto-sensing 802.3at PoE+ ports, and 2 SFP ports. It provides Gigabit PoE links to your RJ45 Ethernet devices and Gigabit fiber uplink options to your enterprise network. The USW-24-POE features a 1.3" touch LCM to provide status information. With a depth of 7.9", the compact fanless design can be easily installed in a SOHO rack cabinet.
Management via UniFi Controller
Managed and configured by the UniFi Network Controller with UniFi mobile app support, the USW-24-POE offers an extensive suite of advanced Layer 2 switching protocols and features, including operation mode (switching, mirroring, or aggregate) per port. The UniFi Network Controller and mobile app allow admins to configure and monitor virtually all of the switch features in a graphical user interface from anywhere.
Package contains
Download
Datasheet Firmware Quick GuideTechnical support for this product is available on rma@discomp.cz email or sending a request via web form. Our technical support is available during this business hours.
