Ubiquiti ACB-AC, airCube AC, DualBand Wi-Fi AP / Router
Ubiquiti ACB-AC, airCube AC, DualBand Wi-Fi AP / Router
×
0/0
Your price excl. VAT
63.35 EUR
| Recycling fee | 0.07 EUR |
|---|---|
| Your price with RF | 63.42 EUR |
| Your price incl. VAT (21%) | 76.74 EUR |
| blank |
Availability
at our branches
at our branches
| Manufacturer |
Ubiquiti |
|
|---|---|---|
| Code | 10110220 | |
| Part No. | ACB-AC | |
| Warranty | 24 months | |
PCU5E-1YW-MS
0.57 EUR excl. VAT
0.69 EUR incl. VAT
In Stock
PCU5E-5-MSC
3.44 EUR excl. VAT
4.16 EUR incl. VAT
In Stock
Parameters
Download
Technical parameters
Wireless features
Wireless frequency:
2.4 + 5 GHz (dual band)
WiFi standards:
802.11ac, 802.11n, 802.11a, 802.11b/g
Transmission speed - 5GHz [Mb/s]:
866
Transmission speed - 2.4GHz [Mb/s]:
300
Tx power 2.4GHz [dBm]:
22
Tx power 5GHz [dBm]:
22
Security:
WPA2 AES
2.4GHz MIMO:
2 x 2
5GHz MIMO:
2 x 2
Type of antenna:
Built-in
Internal antennas:
1
Antenna gain [dBi]:
4, 5
Connectors and Interfaces
WAN speed:
(1) 10/100/1000Mbps
LAN speed:
(3) 10/100/1000Mbps
Gigabit LAN:
Yes
Power
Power over Ethernet:
24V DC
PoE type:
PoE-Out + PoE-In
Max. power consumption [W]:
8,5
Power via connector/terminal:
24V DC
Physical characteristics
Purpose:
Indoor
Buttons:
Reset
Operating temperature [°C]:
-10 up to 50
Weight [g]:
280
Width [mm]:
90
Height [mm]:
88
Depth [mm]:
90
Software
Operating mode:
AP Router, Access Point
Default IP address:
192.168.1.1, Dynamic from DHCP
Default login and password:
ubnt / (preset password, see bottom of router)
Product description
AirCube AC is home router with modern design and very powerful / discrete antenna system hidden under a plastic chassis. The body of the router is in black matt color is complemented by an elegant white backlit base.
The Router features 3x 10/100/1000 Mbps LAN ports (1st LAN port supports PoE IN), 1x 10/100/1000 Mbps LAN/WAN port with PoE output PoE, power connector and 2x2 MIMO WiFi radio supporting 300Mbps speed in 2.4GHz and 5GHz radio part supporting 866Mbps speed.
Powering
Router can be powering via packed 24V power adapter or via 24V passive injector connected to the 1st LAN port, which will also power an outdoor unit such as Loco, PowerBeam, NanoBeam and other CPE connected to the WAN port.
Management
Package contains
Download
Datasheet Quick GuideTechnical support for this product is available on rma@discomp.cz email or sending a request via web form. Our technical support is available during this business hours.
