TP-Link TL-SL1311MP Gigabit PoE Switch

TP-Link TL-SL1311MP Gigabit PoE Switch
TP-Link TL-SL1311MP Gigabit PoE Switch
×
0/0
TP-Link TL-SL1311MP Gigabit PoE Switch
TP-Link TL-SL1311MP Gigabit PoE Switch
TP-Link TL-SL1311MP Gigabit PoE Switch
TP-Link TL-SL1311MP Gigabit PoE Switch
TP-Link TL-SL1311MP Gigabit PoE Switch
TP-Link TL-SL1311MP Gigabit PoE Switch

Your price excl. VAT
110.59 EUR
Recycling fee 0.03 EUR
Your price with RF 110.62 EUR
Your price incl. VAT (21%) 133.85 EUR
blank
In Stock
PlzeňIn Stock
Availability
at our branches
Manufacturer

TP-Link

Code10410639
Part No.TL-SL1311MP
Warranty 60 months
  • Related products2
Masterlan patch cable UTP, Cat5e, 1m, yellow
PCU5E-1YW-MS

0.57 EUR excl. VAT
0.69 EUR incl. VAT
In Stock
Masterlan comfort patch cable UTP, Cat5e, 5m, gray
PCU5E-5-MSC

3.44 EUR excl. VAT
4.16 EUR incl. VAT
In Stock
Parameters
Download
Video

Product description

TP-Link desktop switch TL-SL1311MP is an unmanaged PoE switch with 8× 10/100 Mbps LAN, 2× Gigabit LAN uplink ports and one SFP port. The switch supports the power supply of PoE 802.3af/at devices such as cameras, VoIP, AP on the first 8 ports with a maximum device consumption of 30 W/port, a maximum of 124 W on all eight ports simultaneously. Thanks to the switch, the first 4 ports also enable long-range PoE, up to a distance of 250 m, which is achieved by reducing the line speed to 10 Mbps.

Key Features

  • 8× 10/100 Mbps RJ45 Ports, 2× Gigabit RJ45 Ports, 1× Gigabit SFP Port
  • 8× PoE+ ports transfer data and power on individual cables
  • Works with IEEE 802.3af/at compliant PDs
  • Supports PoE Power up to 30 W for each PoE port
  • Supports PoE Power up to 124 W for 8 PoE ports
  • Up to 250 m data and power transmitting range under Extend Mode
  • Isolation Mode allows one-click client traffic separation for higher security and performance
  • PoE Auto Recovery guarantees stable operation of PoE devices by automatically rebooting the dropped or unresponsive PD devices
  • Fanless Design reduces power consumption and works silently in its location
  • Plug and play with no configuration required

Package Contents

  • Device
  • Power cord
  • 53.5 V/2.4 A power adapter

Download

Datasheet

Bussines information

Luděk Merta, +420 722 926 224 , ludek.merta@discomp.cz

Technical parameters

Connectors and Interfaces

LAN speed: (8) 10/100Mbps + (2) 10/100/1000Mbps
Optical interfaces: (1) 1000Mbps

Power

Power type: DC connector
PoE type: PoE-Out (only)
PoE-Out standards: 802.3af, 802.3at
PoE Out ports: 8
PoE budget [W]: 124
Long range PoE - up to 250m: Yes
Max. power consumption [W]: 141
Power via connector/terminal: 53,5V/2,43A

Physical characteristics

Design: Desktop
Fans: No
Chassis design: Metal
Buttons: Switch mode
Operating temperature [°C]: 0 up to 40
Width [mm]: 209
Height [mm]: 26
Depth [mm]: 126

General

Switchning capacity [Gbps]: 7,6
MAC address table: 2000
Jumbo frame [Bytes]: 16000
Packet forwarding rate [Mpps]: 5,6
