TP-Link EAP660 HD Access Point v2
TP-Link EAP660 HD Access Point v2
×
0/0
Your price excl. VAT
263.85 EUR
| Recycling fee | 0.04 EUR |
|---|---|
| Your price with RF | 263.89 EUR |
| Your price incl. VAT (21%) | 319.31 EUR |
| blank |
Availability
at our branches
at our branches
| Manufacturer |
TP-Link |
|
|---|---|---|
| Code | 10410954 | |
| Part No. | EAP660 HD | |
| Warranty | 60 months | |
MAXPI30
14.41 EUR excl. VAT
17.52 EUR incl. VAT
Expected 12.2.2025
POE160S
17.20 EUR excl. VAT
20.86 EUR incl. VAT
In Stock
D-EAP6X-UNI
20.50 EUR excl. VAT
24.81 EUR incl. VAT
In Stock
PCU5E-1YW-MS
0.57 EUR excl. VAT
0.69 EUR incl. VAT
In Stock
PCU5E-5-MSC
3.46 EUR excl. VAT
4.19 EUR incl. VAT
Expected 12.2.2025
Parameters
Download
GPSR
Technical parameters
Wireless features
Wireless frequency:
2.4 + 5 GHz (dual band)
WiFi standards:
802.11ac, 802.11ax, 802.11n, 802.11a, 802.11b/g
MU-MIMO:
Yes
Transmission speed - 5GHz [Mb/s]:
2402
Transmission speed - 2.4GHz [Mb/s]:
1148
Tx power 2.4GHz [dBm]:
26
Tx power 5GHz [dBm]:
26
Security:
WEP, WPA, WPA2, WPA3
2.4GHz MIMO:
4 x 4
5GHz MIMO:
4 x 4
Type of antenna:
Built-in
Internal antennas:
8
Roaming:
Yes
Antenna gain [dBi]:
5, 6
Connectors and Interfaces
LAN speed:
(1) 100/1000/2500Mbps
Gigabit LAN:
Yes
Power
Power over Ethernet:
802.3at
PoE type:
PoE-In (only)
Max. power consumption [W]:
22,3
Power via connector/terminal:
12V / 2A
Physical characteristics
Purpose:
Indoor
Buttons:
Reset
Operating temperature [°C]:
0 up to 40
Width [mm]:
220
Height [mm]:
33
Depth [mm]:
220
Software
Operating mode:
Access Point
Management:
Omada controller
Default IP address:
Dynamic from DHCP
Default login and password:
admin / admin
Product description
The EAP660 HD is currently best of EAP Access Point with Roaming, which supports the latest wireless protocol 802.11ax with MU-MIMO technology and easily reaches speeds of up to 2402 + 1148 Mbps in a dual-band Wi-Fi network for multiple devices at once, thanks to 4x4 MIMO on both radio parts. At the same time, a Gigabit LAN port would no longer be enough, so the AP was equipped with a LAN port with a speed of up to 2.5Gbps. For great coverage, the AP has 8 built-in antennas, 4 of which operate 2.4GHz radio the antennas take care of 5GHz and have a gain of 6dBi. Thanks to these improvements, the access point also has a higher consumption of 20,3W and can be powered either directly via a 12V DC power adapter or via 802.3at PoE. Great news is encrypting wireless traffic with WPA3.
Easy for Centralized Management
Manage and monitor hundreds of EAPs with ease, all from a single location. The TP-Link Omada Controller software provides an intuitive management interface. Control and map out the entire network from any connected PC. There’s no added cost, and no need for special training. Business Wi-Fi management has never been so efficient and cost-effective.
Efficient Guest Authentication with Facebook and SMS Support
Captive portal helps maintain only authorized guests to use the network, presenting devices with a convenient, user-friendly authentication method to grant Wi-Fi access. The addition of SMS and Facebook authentication simplifies the captive portal even further to simplify connectivity and boost your business.
