TP-Link DS-P7500-08 DeltaStream OLT, 8x XGS-PON/GPON

TP-Link DS-P7500-08 DeltaStream OLT, 8x XGS-PON/GPON
TP-Link DS-P7500-08 DeltaStream OLT, 8x XGS-PON/GPON
×
0/0
TP-Link DS-P7500-08 DeltaStream OLT, 8x XGS-PON/GPON
TP-Link DS-P7500-08 DeltaStream OLT, 8x XGS-PON/GPON
TP-Link DS-P7500-08 DeltaStream OLT, 8x XGS-PON/GPON
TP-Link DS-P7500-08 DeltaStream OLT, 8x XGS-PON/GPON
TP-Link DS-P7500-08 DeltaStream OLT, 8x XGS-PON/GPON
TP-Link DS-P7500-08 DeltaStream OLT, 8x XGS-PON/GPON

Your price excl. VAT
6 134.65 EUR
Recycling fee 0.06 EUR
Your price with RF 6 134.71 EUR
Your price incl. VAT (21%) 7 423.00 EUR
blank
Not in stock
PlzeňNot in stock
Externí sklad EANot in stock
Externí sklad EUNot in stock
Availability
at our branches
Manufacturer

TP-Link

Code10411218
Part No.DS-P7500-08
Warranty 60 months
  • Related products9
TP-Link XGZ030 XGS-PON terminal
XGZ030

130.42 EUR excl. VAT
157.88 EUR incl. VAT
Ordered, unknown date
TP-Link DS-PMA-C++, GPON Class C++ SFP module
DS-PMA-C++

58.68 EUR excl. VAT
71.08 EUR incl. VAT
Expected 11.12.2024
TP-Link DS-PMA-Combo C+, XGS-PON/XG-PON/GPON SFP+ Class C+ optical module
DS-PMA-Combo C+

368.06 EUR excl. VAT
445.43 EUR incl. VAT
Expected 11.12.2024
MaxLink 10G SFP+ optical module, MM, 850nm, 300m, 2x LC connector, DDM
ML-S+85D-03

8.09 EUR excl. VAT
9.87 EUR incl. VAT
In Stock
MaxLink 10G SFP+ optical module, SM, 1310nm, 10km, 2x LC connector, DDM
ML-S+31D-10

13.11 EUR excl. VAT
15.95 EUR incl. VAT
In Stock
MaxLink 10G SFP+ optical module, WDM(BiDi), SM, Tx 1270/Rx1330nm, 10km, 1x LC connector, DDM
ML-S+2733-10

18.56 EUR excl. VAT
22.54 EUR incl. VAT
In Stock
MaxLink 10G SFP+ optical module, WDM(BiDi), SM, Tx 1330/Rx1270nm, 10KM, 1x LC connector, DDM
ML-S+3327-10

18.56 EUR excl. VAT
22.54 EUR incl. VAT
In Stock
Masterlan patch cable UTP, Cat5e, 1m, yellow
PCU5E-1YW-MS

0.57 EUR excl. VAT
0.69 EUR incl. VAT
In Stock
Masterlan comfort patch cable UTP, Cat5e, 5m, gray
PCU5E-5-MSC

3.44 EUR excl. VAT
4.16 EUR incl. VAT
In Stock
show moreshow less 4
Parameters
Download

Product description

DS-P7500-08 is a GPON OLT unit offering 8 XGS-PON/GPON ports, allowing you to connect up to 256 clients per port for XGS-PON or 128 clients per port for GPON, for a total of up to 2048 clients for XGS-PON or 1024 clients for GPON (ONT units) simultaneously with physical links reaching up to 20 km. Additionally, it offers 2x QSFP+, 2x SFP+, 1 Gigabit Ethernet port dedicated for management, 1 RJ45 console port, and an alarm terminal block. For enhanced power reliability, the OLT is equipped with two hot-swappable power supplies, where the second takes over in case of failure of the first. Each power supply also features an LED status indicator.

Data rate

  • GPON: Downstream: 2.5 Gbps, Upstream: 1.25 Gbps
  • XGS-PON: Downstream: 9.953 Gbps, Upstream: 9.953 Gbps

Wavelength

  • GPON: TX:1490nm, RX:1310nm
  • XGS-PON: TX:1577nm, RX:1270nm

Centralized Management via DPMS

Centralized management is conducted through the DeltaStream PON Management System (DPMS). Easy maintenance and centralized management will make your life much simpler. Configure and update all your devices at once using the DeltaStream PON Management System (DPMS), SNMP, CLI, or the web user interface.

TP-Link DS-P7005-08 DeltaStream OLT

Package Contents

  • Device
  • (2) Power cables
  • 19" rack mount brackets

Bussines information

Luděk Merta, +420 722 926 224 , ludek.merta@discomp.cz

Technical parameters

Optics

Transfer type: GPON, XGS-PON

Connectors and Interfaces

PON SFP cages: 8
Optical interfaces: (2) 40G + (2) 10Gbps
Serial port: RJ45

Power

Max. power consumption [W]: 109
Power via connector/terminal: 230V AC (directly to the wall outlet)

Physical characteristics

Fans: Yes
Buttons: Reset
Operating temperature [°C]: 0 up to 50
Width [mm]: 440
Height [mm]: 44
Depth [mm]: 330
