TP-Link DS-P7001-01 DeltaStream OLT, 1x GPON
Your price excl. VAT
723.61 EUR
Recycling fee | 0.06 EUR |
---|---|
Your price with RF | 723.67 EUR |
Your price incl. VAT (21%) | 875.64 EUR |
blank |
Availability
at our branches
at our branches
Manufacturer |
TP-Link |
|
---|---|---|
Code | 10411223 | |
Part No. | DS-P7001-01 | |
Warranty | 60 months |
You have a choice of 3 variantscompare all
DS-PMA-C++
58.76 EUR excl. VAT
71.17 EUR incl. VAT
Expected 11.12.2024
DS-PMA-Combo C+
368.56 EUR excl. VAT
446.03 EUR incl. VAT
Expected 11.12.2024
ML-S+85D-03
8.46 EUR excl. VAT
10.32 EUR incl. VAT
In Stock
ML-S+31D-10
13.68 EUR excl. VAT
16.64 EUR incl. VAT
In Stock
ML-S+2733-10
18.58 EUR excl. VAT
22.57 EUR incl. VAT
In Stock
ML-S+3327-10
18.58 EUR excl. VAT
22.57 EUR incl. VAT
In Stock
PCU5E-1YW-MS
0.57 EUR excl. VAT
0.69 EUR incl. VAT
In Stock
PCU5E-5-MSC
3.44 EUR excl. VAT
4.16 EUR incl. VAT
In Stock
Parameters
Download
Technical parameters
Optics
Transfer type:
GPON
Connectors and Interfaces
LAN speed:
(1) 100/1000/2500Mbps
PON SFP cages:
1
Optical interfaces:
(1) 10Gbps
Serial port:
RJ45
Power
Max. power consumption [W]:
17
Power via connector/terminal:
12V / 2,5A
Physical characteristics
Buttons:
Reset
Operating temperature [°C]:
0 up to 50
Width [mm]:
294
Height [mm]:
44
Depth [mm]:
140
Product description
DS-P7001-01 is a GPON OLT unit with one GPON port supporting up to 128 clients (ONT units) with physical links reaching distances of up to 60 km. It features 1x SFP+ and 1x 2.5 Gigabit Ethernet as uplink, 1 Gigabit Ethernet for management only and RJ45 console port. For flexibility of your deployment, the OLT supports both DC 12V/2,5A and 802.3at PoE power supplies
Centralized Management via DPMS
Centralized management is done through the DeltaStream PON Management System (DPMS). Easy maintenance and centralized management will make your life much easier. Configure and update all your devices at once using DeltaStream PON Management System (DPMS), SNMP, CLI, or the web-based user interface.
Package Contents
Download
Datasheet User guideTechnical support for TP-LINK products is available at support.cz@tp-link.com email or on telephone number (+420) 212 812 622. Both services are available on working days between 9:00 and 17:00 with the first response to the latest 24 hours.
