REBEL backup power UPS 500W 230V, 12V, wall mount

REBEL backup power UPS 500W 230V, 12V, wall mount
REBEL backup power UPS 500W 230V, 12V, wall mount
×
0/0
REBEL backup power UPS 500W 230V, 12V, wall mount
REBEL backup power UPS 500W 230V, 12V, wall mount
REBEL backup power UPS 500W 230V, 12V, wall mount
REBEL backup power UPS 500W 230V, 12V, wall mount
REBEL backup power UPS 500W 230V, 12V, wall mount
REBEL backup power UPS 500W 230V, 12V, wall mount
REBEL backup power UPS 500W 230V, 12V, wall mount
REBEL backup power UPS 500W 230V, 12V, wall mount
REBEL backup power UPS 500W 230V, 12V, wall mount
REBEL backup power UPS 500W 230V, 12V, wall mount

Your price excl. VAT
79.30 EUR
Recycling fee 0.34 EUR
Your price with RF 79.64 EUR
Your price incl. VAT (21%) 96.36 EUR
blank
In Stock
PlzeňIn Stock
Availability
at our branches
Manufacturer

OEM

Code10930244
Part No.RB-4012
Warranty 24 months
  • Related products3
Extension cable 1.5m, 6x socket
ppr15/6

4.14 EUR excl. VAT
5.01 EUR incl. VAT
Not in stock
Masterlan 19" distribution panel 8x230V, black, 2m, aluminium
PDU-FRS5208

22.57 EUR excl. VAT
27.36 EUR incl. VAT
In Stock
Masterlan 19" distribution panel - combi
PDU-COMBI

27.59 EUR excl. VAT
33.43 EUR incl. VAT
In Stock
Parameters
Download

Product description

We recommend this backup unit for its flexible use. Pure sine wave output. Ideal for long-term backups. When powered from the mains, the connected appliances are powered directly from the mains, the external battery is recharged, when the mains fails, the source automatically switches to the voltage converter, energy is taken from the battery, the appliances are powered from the converter. After restoring electricity energy source will automatically switch to the mains, the battery will start charging.

Key features:

  • Rated power: 500 W
  • Battery voltage: 12 V DC
  • Maximum battery voltage: 15 V DC
  • Input voltage range: 180 - 275 V AC
  • Input frequency: 45 - 60 Hz
  • Output voltage range: 230 V AC +/-5% / Converter: 230 VAC +/-3%
  • Output frequency: 50/60 Hz +/-0.5 Hz
  • Output voltage waveform: Pure sine wave
  • Output efficiency: >= 85% (DC to AC)
  • Battery charging current: Max.10 A
  • Max. battery capacity: 100 Ah
  • Switching time: =< 4 ms
  • Protection: Against overload, short circuit, overvoltage, undervoltage

Bussines information

Adéla Gygalová, +420 377 221 177 , adela.gygalova@discomp.cz

Technical parameters

Connectors and Interfaces

Quantity of sockets (standard): 2
Connector for external battery: Yes

Power

Power [W]: 500
Technology: Off-line

Physical characteristics

Design: On the wall
Operating temperature [°C]: 0 up to 40
Weight [kg]: 4,7
Width [mm]: 215
Height [mm]: 265
Depth [mm]: 100
