Mimosa C5c, PTP and PtMP unit, 2x RSMA female, PoE injector
We are sorry, this product is no longer in our offer.
| Manufacturer |
Mimosa |
|
|---|---|---|
| Code | 10160051 | |
| Part No. | 100-00072(C5c) | |
You have a choice of 2 variantscompare all
Device + PoE Injector
100-00072(C5c)
139.67 EUR
TP-ADAP-C5c
13.32 EUR excl. VAT
16.19 EUR incl. VAT
In Stock
100-00039(NID)
13.28 EUR excl. VAT
16.15 EUR incl. VAT
Expected 30.6.2025
PCU5E-1YW-MS
0.61 EUR excl. VAT
0.74 EUR incl. VAT
In Stock
PCU5E-5-MSC
3.69 EUR excl. VAT
4.46 EUR incl. VAT
In Stock
Parameters
Download
Video
GPSR
Technical parameters
Wireless features
Sensitivity [dBm]:
-93
Wireless frequency:
5 GHz
WiFi standards:
Mimosa SRS, WiFi Interop
MU-MIMO:
Yes
Transmission speed - 5GHz [Mb/s]:
866
Tx power 5GHz [dBm]:
27
Security:
WPA2 PSK & Enterprise 802.1x;Radius provisioning, COA, DM; 128-bit AESwith hardware acceleration
5GHz MIMO:
2 x 2
Type of antenna:
Detachable
Detachable antennas:
2
Connectors and Interfaces
RF connectors:
(2) RSMA female
LAN speed:
(1) 10/100/1000Mbps
Gigabit LAN:
Yes
Power
Power over Ethernet:
24 .. 56V DC
PoE type:
PoE-In (only)
Max. power consumption [W]:
12,9
Physical characteristics
Purpose:
Outdoor
Operating temperature [°C]:
-40 up to 55
Weight [g]:
295
Width [mm]:
65
Height [mm]:
188
Depth [mm]:
44
Software
Operating mode:
Client, Bridge
Default IP address:
192.168.1.20
Default login and password:
Is set by the user at the first startup
Video
Product description
C5c has been designed specifically to handle long-range backhaul (PTP), point-to-multipoint (PTMP) GigaPoP links, and PTMP MicroPoP links impaired by vegetation. Connectorized by design, the C5c mates with many popular antennas, delivering 500+ Mbps of TCP throughput.
Package contains
Download
Datasheet Firmware Product overviewGPSR
