MikroTik D53G-5HacD2HnD-TC&RG520F-EU, Chateau 5G R16
MikroTik D53G-5HacD2HnD-TC&RG520F-EU, Chateau 5G R16
×
0/0
Your price excl. VAT
357.92 EUR
| Recycling fee | 0.07 EUR |
|---|---|
| Your price with RF | 357.99 EUR |
| Your price incl. VAT (21%) | 433.17 EUR |
| blank |
Availability
at our branches
at our branches
| Manufacturer |
MikroTik |
|
|---|---|---|
| Code | 10904162 | |
| Part No. | D53G-5HacD2HnD-TC&RG520F-EU | |
| Warranty | 24 months | |
PCU5E-1YW-MS
0.57 EUR excl. VAT
0.69 EUR incl. VAT
In Stock
PCU5E-5-MSC
3.46 EUR excl. VAT
4.19 EUR incl. VAT
Expected 12.2.2025
Parameters
Download
GPSR
Technical parameters
Wireless features
Sensitivity [dBm]:
-100
Wireless frequency:
2.4 + 5 GHz (dual band), LTE, 3G (GSM), 5G (GSM)
WiFi standards:
802.11n, 802.11a, 802.11ac, 802.11b/g
Transmission speed - 5GHz [Mb/s]:
866
Transmission speed - 2.4GHz [Mb/s]:
300
Tx power 2.4GHz [dBm]:
26
Tx power 5GHz [dBm]:
26
2.4GHz MIMO:
2 x 2
5GHz MIMO:
2 x 2
Type of antenna:
Built-in
Internal antennas:
4
Antenna gain [dBi]:
3, 5,5
Integrated 4G/LTE radio part:
Yes
4G/LTE bands support:
(1) 2100 MHz, (3) 1800 MHz, (7) 2600 MHz, (8) 900 MHz, (20) 800 MHz, (38) 2600 MHz, (40) 2300 MHz, (5) 850 MHz, (41) 2500 MHz, (42) 3500 MHz, (43) 3700 MHz, (28) 700 MHz, (32) 1500 MHz
5G bands support:
(n1) 2100 MHz, (n3) 1800 MHz, (n5) 850 MHz, (n7) 2600 MHz, (n8) 900 MHz, (n20) 800 MHz, (n28) 700 MHz, (n38) 2600 MHz, (n40) 2300 MHz, (n41) 2500 MHz, (n75) 1500 MHz, (n76) 1500 MHz, (n77) 3700 MHz, (n78) 3500 MHz
Connectors and Interfaces
M.2 slots:
1
LAN speed:
(5) 10/100/1000Mbps
Gigabit LAN:
Yes
USB ports 2.0:
1
SIM slot:
Yes
SIM slots quantity:
1
USB:
Yes
Power
Power type:
DC connector
Max. power consumption [W]:
25
Power via connector/terminal:
12 .. 28V DC
Physical characteristics
Design:
Desktop
Purpose:
Indoor
Buttons:
Reset, mode
Operating temperature [°C]:
-40 up to 70
Width [mm]:
240
Height [mm]:
156
Depth [mm]:
44
Hardware
CPU:
IPQ-4019
CPU frequency [MHz]:
896
CPU cores:
4
Internal storage [MB]:
16
RAM [MB]:
256
Software
Operating mode:
AP Router, Cellular router
Operating system:
RouterOS v7 - L4
IPv6 support:
Yes
Default IP address:
192.168.88.1
Default login and password:
admin / -
Product description
Mikrotik Chateau 5G R16 is a home dual-band router for very demanding users. Quality connectivity anywhere is ensured by supporting 4G and 5G and simultaneously using the LTE module or classic 2.5GHz and 5GHz. For LAN connectivity, the router features 5 ports with 1Gbps speed. To improve the signal, additional antennas can be added via SMA connectors. Expanding the use of your router can also be achieved by adding a module to an available M.2 slot. There is also a USB port for connecting external devices.
Key Features:
Package contents:
