UPS MaxLink 500W, 12V pure sine wave

We are sorry, this product is no longer in our offer.

UPS MaxLink 500W, 12V pure sine wave
UPS MaxLink 500W, 12V pure sine wave
×
0/0
UPS MaxLink 500W, 12V pure sine wave
UPS MaxLink 500W, 12V pure sine wave
UPS MaxLink 500W, 12V pure sine wave
UPS MaxLink 500W, 12V pure sine wave
UPS MaxLink 500W, 12V pure sine wave
UPS MaxLink 500W, 12V pure sine wave
Recommended
Manufacturer

MaxLink

Code10930200
Part No.sinusPRO-800E (black)
  • Related products3
Masterlan 19" distribution panel 8x230V, black, 2m, aluminium
PDU-FRS5208

22.45 EUR excl. VAT
27.21 EUR incl. VAT
In Stock
Extension cable 1.5m, 6x socket
ppr15/6

4.12 EUR excl. VAT
4.99 EUR incl. VAT
In Stock
Masterlan 19" distribution panel - combi
PDU-COMBI

27.43 EUR excl. VAT
33.24 EUR incl. VAT
In Stock
Parameters

Product description

UPS Maxlink is power source with robust construction, flexible use and pure sine output. Thanks to connec external battery it is ideal device also for long-time backup. Length of wires for battery is 0,8m.

When powered from mains, the connected devices are powered by mains voltage and the external battery is recharged. In the event of a power failure, the voltage inverter is activated, the power is supplied from the battery and the devices are powered by the inverter. After restoring the mains voltage automatically switches back to the network and starts charging the battery.

  • Max. continuous output power: 500W
  • Input battery voltage: 12V
  • Battery capacity: 40-150Ah
  • Automatic voltage regulation 140 - 275VAC
  • Switch to battery when U < 160V (+-5V) or U > 260V (+- 5V)
  • Overload protect (powered from battery) - 110-130% output power for 30sec, immediate shutdown when output power is >130%
  • Overload protect (powered from mains) - until the fuse is damaged
  • Output power (powered from battery) 230V (+-3%)
  • Input power frequency 45Hz - 65Hz
  • Output power frequency 50Hz (+- 0,5Hz)
  • Operating humidity 10-90% relative

Technical support for this product is available on rma@discomp.cz email or sending a request via web form. Our technical support is available during this business hours.

Bussines information

Adéla Gygalová, +420 377 221 177 , adela.gygalova@discomp.cz

Technical parameters

Connectors and Interfaces

Quantity of sockets (standard): 2
Connector for external battery: Yes

Power

Power [W]: 500
Technology: Off-line

Physical characteristics

Design: Desktop
Operating temperature [°C]: 0 up to 40
Weight [kg]: 5
Width [mm]: 145
Height [mm]: 180
Depth [mm]: 230
