IgniteNet MetroLinq 60 PRO, 2.5Gbps, outdoor unit 60GHz PTP 42dBi + backup 5GHz, 2x22dBi (price per piece), no holder
We are sorry, this product is no longer in our offer.
IgniteNet MetroLinq 60 PRO, 2.5Gbps, outdoor unit 60GHz PTP 42dBi + backup 5GHz, 2x22dBi (price per piece), no holder
×
0/0
Sale
ICC-LA-BT
5.59 EUR excl. VAT
6.76 EUR incl. VAT
In Stock
ICC-BRACKET-LC
22.24 EUR excl. VAT
26.91 EUR incl. VAT
In Stock
PCU5E-1YW-MS
0.57 EUR excl. VAT
0.69 EUR incl. VAT
In Stock
PCU5E-5-MSC
3.45 EUR excl. VAT
4.17 EUR incl. VAT
In Stock
Parameters
Download
Video
Technical parameters
Wireless features
Sensitivity [dBm]:
-74
Channel bandwidth [MHz]:
2000
Transmission speed - 5GHz [Mb/s]:
866
Transmission speed - 60GHz [Mb/s]:
4600
Output power 60GHz [dBm]:
14
Elevation beam width (-6dB) [°]:
3
Azimuth beam width (-6dB) [°]:
3
Antenna gain [dBi]:
38
Connectors and Interfaces
LAN speed:
(1) 100/1000/2500Mbps
Optical interfaces:
(1) 1000Mbps
Power
Power over Ethernet:
24 .. 48V DC
Power type:
PoE, DC terminal
Physical characteristics
Radom:
Yes
Operating temperature [°C]:
-30 up to 55
Weight [g]:
2000
Width [mm]:
190
Height [mm]:
220
Depth [mm]:
120
Software
Default IP address:
192.168.1.20, Dynamic from DHCP
Default login and password:
root / admin123
Product description
IgniteNetTM’s MetroLinq™ 2.5 - 60 is the world’s first cost-effective high capacity 60GHz PTP radio enabling high performance, interference-free connections worldwide. The MetroLinq™ 2.5 - 60 has an added advantage of being license-free in most markets globally, allowing ultra fast deployment and without the hassle of other frequency bands requiring a license. The MetroLinq™ also includes a second 5GHz radio which can be configured as PtP (backup) to provide integrated redundancy without and additional hardware or complexity.
Key Features and Benefits
The IgniteNet™ MetroLinq™ 2.5 - 60 offers unprecedented performance - combining both the benefits of unlicensed band operation with no interference!
The MetroLinq™ 2.5 - 60 includes a second 5GHz radio which can be configured as a backup to the 60GHz to provide automatic failover during adverse conditions. This allows links to be extended further without effecting link availability
The MetroLinq™ Base Station can operate either as a stand-alone device or as a coordinated, cloud-managed device, easily meeting the requirements of any installation
The MetroLinq™ Base Station features a hybrid metal/plastic design built to withstand the harshest environments including precipitation, hot/cold weather and high/low humidities
Package contains
Articles and reviews
60GHz v České republice legálně od 15.1.2020! [CZ]Download
CE RF Test report 60GHz Datasheet DoC Link calculatorTechnical support for this product is available on rma@discomp.cz email or sending a request via web form. Our technical support is available during this business hours.
