Huawei AP162E - WiFi6 indoor Dual Band AP, smart antenna
Huawei AP162E - WiFi6 indoor Dual Band AP, smart antenna
×
0/0
New product
Your price excl. VAT
71.33 EUR
| Recycling fee | 0.06 EUR |
|---|---|
| Your price with RF | 71.39 EUR |
| Your price incl. VAT (21%) | 86.38 EUR |
| blank |
Availability
at our branches
at our branches
| Manufacturer |
Huawei |
|
|---|---|---|
| Code | 10907099 | |
| Part No. | AP162E | |
| Warranty | 36 months | |
PCU5E-1YW-MS
0.57 EUR excl. VAT
0.69 EUR incl. VAT
In Stock
PCU5E-5-MSC
3.44 EUR excl. VAT
4.16 EUR incl. VAT
In Stock
Parameters
Download
Technical parameters
Wireless features
Maximum modulation:
1024 QAM
Wireless frequency:
2.4 + 5 GHz (dual band)
WiFi standards:
802.11n, 802.11a, 802.11ac, 802.11b/g, 802.11ac - wave2, 802.11ax
MU-MIMO:
Yes
Transmission speed - 5GHz [Mb/s]:
2402
Transmission speed - 2.4GHz [Mb/s]:
574
Tx power 2.4GHz [dBm]:
20
Tx power 5GHz [dBm]:
20
Security:
WPA, WPA2, WPA3
2.4GHz MIMO:
2 x 2
5GHz MIMO:
2 x 2
Type of antenna:
Built-in
Roaming:
Yes
Antenna gain [dBi]:
3, 2
Connectors and Interfaces
LAN speed:
(2) 10/100/1000Mbps
Gigabit LAN:
Yes
Power
Power over Ethernet:
802.3af
Max. power consumption [W]:
9
Physical characteristics
Purpose:
Indoor
Buttons:
Reset
Operating temperature [°C]:
0 up to 40
Weight [g]:
140
Width [mm]:
86
Height [mm]:
86
Depth [mm]:
43
Software
Operating mode:
Access Point
IPv6 support:
Yes
Product description
The Huawei eKitEngine AP162E is a compact and powerful indoor access point (AP) designed according to the Wi-Fi 6 (802.11ax) standard, providing fast and reliable wireless connectivity with data transfer speeds of up to 2.975 Gbps. It supports simultaneous transmission on 2.4 GHz (2x2 MIMO) and 5 GHz (2x2 MIMO) frequencies, enabling smooth connections for multiple devices. With its slim design, it is ideal for installation in hotel rooms, hospital rooms, or small and medium business offices.
This access point is equipped with one Gigabit uplink port and one Gigabit downlink port, providing flexible connectivity options. It can be mounted into a wall box, ensuring discreet installation. Its small size and easy installation make the AP162E an excellent choice for quickly establishing an indoor wireless network.
The management and maintenance of the AP162E can be done locally through EasyWeb or a local controller (WAC), or remotely via the HUAWEI eKit App and SNC platform. This makes deployment and management of access points simple and efficient, significantly easing network operation and maintenance.
The MU-MIMO technology allows simultaneous data transmission to multiple devices, maximizing radio spectrum utilization and enhancing network performance in high-density device environments. Support for 160 MHz bandwidth and 1024-QAM modulation enables speeds of up to 575 Mbps (2.4 GHz) and 2.4 Gbps (5 GHz), providing fast and stable connectivity for all users.
Advanced security features include authentication and encryption methods such as WPA3, WPA2, and 802.1X, ensuring maximum data protection in your wireless network. The AP162E is therefore not only a fast but also a secure solution for modern wireless networks.
