Cambium Networks PTP 550E Integrated 5 GHz (EU) with EU Line Cord
Cambium Networks PTP 550E Integrated 5 GHz (EU) with EU Line Cord
×
0/0
Your price excl. VAT
912.82 EUR
| Recycling fee | 0.20 EUR |
|---|---|
| Your price with RF | 913.02 EUR |
| Your price incl. VAT (21%) | 1 104.75 EUR |
| blank |
Availability
at our branches
at our branches
| Manufacturer |
Cambium Networks |
|
|---|---|---|
| Code | 17700077 | |
| Part No. | C050055H015B | |
| Warranty | 36 months | |
You have a choice of 2 variantscompare all
Integrated Antenna (EU)
C050055H015B
912.82 EUR
ETH-SP-G2
9.99 EUR excl. VAT
12.17 EUR incl. VAT
In Stock
N000000L034B
27.91 EUR excl. VAT
33.87 EUR incl. VAT
In Stock
PK35S421V100
12.46 EUR excl. VAT
15.08 EUR incl. VAT
In Stock
CT-290-48-B
6.33 EUR excl. VAT
7.66 EUR incl. VAT
In Stock
OFTP5E24-MSC
130.14 EUR excl. VAT
157.47 EUR incl. VAT
In Stock
PCU5E-1YW-MS
0.57 EUR excl. VAT
0.69 EUR incl. VAT
In Stock
PCU5E-5-MSC
3.46 EUR excl. VAT
4.19 EUR incl. VAT
Expected 12.2.2025
Parameters
Download
GPSR
Technical parameters
Wireless features
Frequency range [MHz]:
4900 - 6200
Wireless frequency:
5 GHz
WiFi standards:
802.11ac - wave2
Transmission speed - 5GHz [Mb/s]:
1400
Tx power 5GHz [dBm]:
23
Security:
128bit AES
5GHz MIMO:
4 x 4
Type of antenna:
Built-in
Antenna gain [dBi]:
23
Connectors and Interfaces
SFP cage:
Yes
LAN speed:
(1) 1000Mbps
Gigabit LAN:
Yes
Optical interfaces:
(1) 1000Mbps
Power
Power over Ethernet:
802.3at
PoE type:
PoE-In (only)
Max. power consumption [W]:
30
Physical characteristics
Protection class:
IP67
Purpose:
Outdoor
Operating temperature [°C]:
-40 up to 60
Weight [g]:
2200
Width [mm]:
305
Height [mm]:
305
Depth [mm]:
68
Software
Operating mode:
Client
Management:
Web management, Cambium cnMaestro cloud
IPv6 support:
Yes
Product description
PTP 550E is a Point to Point Gigabit throughput solution based on 802.11ac Wave 2 operating in 5 GHz wireless space, addressing the gigabit capacity needs for high speed backhaul solutions in short range and middle range applications provides up to 1.36 Gbps throughput with ARQ and asymmetric non-contiguous channel aggregation across 5 GHz band. The PTP 550E solution draws its attributes from Cambium Networks’ Point to Point products such as PTP 650/670 and PTP 450i. Each PTP 550E radio is enclosed in a rugged IP66/67 rated metal enclosure, which protects the radio from extreme conditions and solar radiation.
Key Features
Download
Datasheet Quick Guide User GuideGPSR
