Cambium Networks cnPilot R201 Router
We are sorry, this product is no longer in our offer.
Cambium Networks cnPilot R201 Router
×
0/0
PCU5E-1YW-MS
0.57 EUR excl. VAT
0.69 EUR incl. VAT
In Stock
PCU5E-5-MSC
3.46 EUR excl. VAT
4.19 EUR incl. VAT
Expected 12.2.2025
Parameters
Download
GPSR
Technical parameters
Wireless features
Wireless frequency:
2.4 + 5 GHz (dual band)
WiFi standards:
802.11ac, 802.11n, 802.11a, 802.11b/g
Transmission speed - 5GHz [Mb/s]:
866
Transmission speed - 2.4GHz [Mb/s]:
300
Security:
WEP, WPA, WPA2
2.4GHz MIMO:
2 x 2
5GHz MIMO:
2 x 2
Type of antenna:
Fixed
Fixed antennas:
2
Antenna gain [dBi]:
5
Connectors and Interfaces
WAN speed:
(1) 10/100/1000Mbps
LAN speed:
(4) 10/100/1000Mbps
Gigabit LAN:
Yes
USB ports 2.0:
1
USB:
Yes
Power
Power via connector/terminal:
12V / 2A
Physical characteristics
Purpose:
Indoor
Operating temperature [°C]:
5 up to 45
Width [mm]:
155
Height [mm]:
35
Depth [mm]:
175
Software
Operating mode:
AP Router
IPv6 support:
Yes
Product description
cnPilot R201 is an indoor access point 2×2 MIMO in the 2.4GHz band (802.11n) and 5GHz (802.11ac) including a telephone adapter (ATA) function that combines the simplicity of installation and easy management using the cnMaestro cloud solution.
cnPilot R201 is the ideal solution for operators who want to expand their network to living or warehouse space, small offices, companies and institutions where it is necessary to provide Wi-Fi connections for devices such as smartphones, tablets or laptops.
cnPilot R201 is equipped with four 1000Mbps Ethernet ports, one port 1000Mbps WAN, one USB 2.0 port for printer connection, or file sharing further 2.4GHz (802.11n) and 5GHz (802.11ac) wireless part + 2x FXS telephone ports (SIP protocol support). The cnPilot series allows you to expand the services provided with multiple SSIDs.
Package contents
Download
DatasheetGPSR
